UNISONIC TECHNOLOGIES CO., LTD

U74LVC2G02

CMOS IC

www.unisonic.com.tw

1 of 5

QW-R502-790.A

DUAL 2-INPUT POSITIVE-NOR

GATE

DESCRIPTION

The UTC U74LVC2G02 is a dual 2-input positive-NOR gate

which provides the function

Y=A+B or Y=A+B .

This device has power-down protective circuit, preventing device

destruction when it is powered down.

FEATURES

* Operation Voltage Range: 1.65~5.5V

* Low Power Dissipation: ICC=10μA(Max)

* High Speed: tpd=4.9ns(VCC=3.3V)

* Specified from -40 to +85°C

ORDERING INFORMATION

Ordering Number

Package

Packing

Lead Free Plating

Halogen Free

U74LVC2G02L-S08-R

U74LVC2G02G-S08-R

SOP-8

Tape Reel

U74LVC2G02L-S08-T

U74LVC2G02G-S08-T

SOP-8

Tube
