background image
2SD2686
Preliminary
NPN EPITAXIAL SILICON TRANSISTOR
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R208-050.a
ABSOLUTE MAXIMUM RATINGS (TA=25°C, unless otherwise specified)
PARAMETER
SYMBOL
RATINGS
UNIT
Collector-Base Voltage
VCBO
50
V
Collector-Emitter Voltage
VCEO
60±10
V
Emitter-Base Voltage
VEBO
8
V
Collector Current
DC
IC
1
A
Pulse
ICP
3
A
Base Current
IB
0.5
A
Power Dissipation (Note 2)
PD
500
mW
Junction Temperature
TJ
150
°C
Storage Temperature
TSTG
-55~+150
°C
Note: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
2. Mounted on an FR4 board (glass-epoxy; 1.6mm thick; Cu area, 645mm
2)
ELECTRICAL CHARACTERISTICS (TA =25°C, unless otherwise specified)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN TYP MAX UNIT
Collector-Emitter Breakdown Voltage
BVCEO
IC=10mA, IB=0
50
60
70
V
Collector Cut-Off Current
ICBO
VCB=45V, IE=0
10
μA
ICEO
VCE=45V, IE=0
10
μA
Emitter Cut-Off Current
IEBO
VEB=8V, IC=0
0.8
4.0
mA
DC Current Gain
hFE
VCE=2V, IC=1.0A
2000
Collector-Emitter Saturation Voltage
VCE(sat)
IC=0.5A, IB=1mA
1.2
V
IC=1.0A, IB=1mA
1.5
V
Base-Emitter Saturation Voltage
VBE(sat)
IC=1.0A, IB=1mA
2.0
V
Turn-On Time
tON
See specified test circuit.
0.4
μs
Storage Time
tSTG
4.0
μs
Fall Time
tF
0.6
μs
