USB4S012

Preliminary

TVS

UNISONICTECHNOLOGIESCO.,LTD

3 of 4

www.unisonic.com.tw

QW-R215-010.a



PARAMETER

SYMBOL

RATINGS

UNIT

-0.3~20

V

IO Voltage Tolerance

-0.3~6

V

IEC 61000-4-2 Contact Discharge

D+, D–, ID

±10

kV

IEC 61000-4-2 Air-Gap Discharge

D+, D–, ID

±10

kV

IEC 61000-4-2 Contact Discharge

±10

kV

IEC 61000-4-2 Air-Gap Discharge

±9

kV

Peak pulse power (tp = 8/20 μs)

60

W

Peak pulse current (tp = 8/20 μs)

3

A

Storage Temperature Range

-65~125

°C

Operating Free-Air Temperature Range

-40~85

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS

over operating free-air temperature range (unless otherwise noted)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

D+, D–, ID pins open

μA

0.1

0.5

IO Port Current

D+, D–, ID pins

0.1

0.5

μA

Diode Forward Voltage

D+, D–, ID pins (lower clamp

diode)

0.6

0.8

0.95

V

11

15

pF

IO Capacitance

D+, D–, ID pins (DRY package)

0.8

1

pF

Dynamic Resistance

including central clamp dioded

during positive ESD pulse

1.2

Ω

including central clamp diode

during negative ESD pulse

1

Breakdown Voltage

D+, D–, ID pins

6

9

V

20

24
