UU642
Preliminary
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
2 of 5
www.unisonic.com.tw
QW-R121-022.a
PIN CONFIGURATION
1
2
3
4
8
7
6
5
GND
RT
CT
INT
WASH
PA RK
OUT
VS
PIN DESCRIPTION
PIN NO.
PIN NAME
DESCRIPTION
1
GND
Ground
2
INT
Interval switch
3
CT
Timing capacitor C2
4
RT
After-wiping time resistance
5
WASH
Wipe/wash switch
6
PARK
Park switch for wiper motor
7
OUT
Relay control output
8
VS
Supply voltage terminal 15
BLOCK DIAGRAM
VS
8
7
OUT
6
PARK
5
WASH
VRef
VRef
Logic
Load-dump
comparator
Park switch
comparator
Input
comparator
VRef
VRef
Wipe/wash
comparator
Interval
AB
C
D
E
F
GND
1
INT
2
Ct
3
Rt
4
comparator
