VF8143
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
2 of 5
www.unisonic.com.tw
QW-R502-956.a
PIN CONFIGURATION
PIN DESCRIPTION
PIN NO.
PIN NAME
DESCRIPTION
1
IN1
Video input, Channel 1
2
IN2
Video input, Channel 2
3
IN3
Video input, Channel 3
4
VCC
+5V supply, do not float
5
GND
Must be tied to ground, do not float
6
OUT3
Filtered output, Channel 3
7
OUT2
Filtered output, Channel 2
8
OUT1
Filtered output, Channel 1
