BZT52CXXXS

Preliminary

ZENER DIODE

UNISONICTECHNOLOGIESCO.,LTD

2 of 3

www.unisonic.com.tw

QW-R601-091.b



Single phase, half wave, 60Hz, resistive or inductive load. For capacitance load, derate current by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

Forward Voltage (Note)

0.9

V

Thermal characteristics

Power Dissipation (Note 2)

200

mW

Operating Temperature

-55~+150

°C

Storage Temperature

-55~+150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



Device

Marking

Code

Nominal Zener Voltage

Zener Impedance

Reverse Leakage

Current (Note)

Zener

Current

mA

MIN

TYP MAX

mA

TYP (Ω)

mA

TYP (µA) TYP (V)

MIN MAX

BZT52C5V6S

5.6

5.20 5.60

6.0

5

40

400

1.0

3

2.0

-2.0

2.5

BZT52C6V2S

6.2

6.08

6.2

6.32

5

10

150

1.0

2

4.0

0.4

3.7

BZT52C16S

16

15.68

16

16.32

5

40

200

1.0

0.1

11.2

10.4 14.0

Note: Short duration pulse test used to minimize self-heating effect.
