SLVU2.8
Preliminary
DIODE
UNISONICTECHNOLOGIESCO.,LTD
2 of 3
www.unisonic.com.tw
QW-R601-087.a
ABSOLUTE MAXIMUM RATINGS
PARAMETER
SYMBOL
RATINGS
UNIT
Peak Pulse Current (tp=8/20µs)
IPP
24
A
Peak Pulse Power (tp=8/20µs)
PPK
400
W
Lead Soldering Temperature
TL
260 (10 seconds)
°C
Storage Temperature
TSTG
-55~+150
°C
Operating Junction Temperature
TJ
-55~+125
°C
Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.
Absolute maximum ratings are stress ratings only and functional device operation is not implied.
ELECTRICAL CHARACTERISTICS
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX UNIT
Reverse Stand-Off Voltage
VRWM
Pin 3 to 2 or Pin 1 to 2
2.8
V
Punch-Through Voltage
VPT
IPT=2µA, Pin 3 to 2
3.0
V
Snap-Back Voltage
VSB
ISB=50mA, Pin 3 to 2
2.8
V
Reverse Leakage Current
IR
VRWM=2.8V, T=25°C, Pin 3 to 2 or
Pin 1 to 2
1
µA
Clamping Voltage
VC
IPP=2A, tp=8/20µs, Pin 3 to 2
3.9
V
IPP=5A, tp=8/20µs, Pin 3 to 2
7
V
IPP=24A, tp=8/20µs, Pin 3 to 2
12.5
V
IPP=5A, tp=8/20µs, Pin 1 to 2
8.5
V
IPP=24A, tp=8/20µs, Pin 1 to 2
15
V
Junction Capacitance
Cj
Pin 3 to 2 and 1 (Pin 2 and 1 Tied
Together), VR=0V, f=1MHz
70
100
pF
Pin 1 to 2 (Pin 3 N.C.), VR=0V,
f=1MHz
5
10
pF
Steering Diode Characteristics
Reverse Breakdown Voltage
VBR
IT=10µA, Pin 3 to 1
40
V
Reverse Leakage Current
IRD
VRWM=2.8V, T=25°C, Pin 3 to 1
1
µA
Forward Voltage
VF
IF=1A, Pin 1 to 3
2
V
