A B

C

D

E

G

H

J

Key Features

!

!

Benefits

1.

Low power loss / highly efficient.

2.

Can operate at very high frequencies / conducive to switch-mode circuits.

3.

Very small package allows for greater circuit density and reduced PCB area consumption.

End Equipment Applications

Computer Motherboard, Portable Applications, and Handheld Devices:

!

PWM Controller circuit in motherboard

!

Low ripple 5V to –3V “Cuk” Converter

!

5V to 3.3VDC, 4 Amp Synchronous Step-Down Power Supply Controller

!

Low Voltage Micro to Motor Interface

Can be used for clamping, protection, and detection

Availability

!

Samples Now Available

!

Production Quantities stock to 4-6 weeks

!

Data Sheet available NOW at: http://www.diodes.com/datasheets/ds30235.pdf

SOD-323

Dim

Min

Max

A

2.30

2.70

B

1.60

1.80

C

1.20

1.40

D

1.05 Typical

E

0.25

0.35

G

0.20

0.40

H

0.10

0.15

J

0.05 Typical

All Dimensions in mm

New Product Announcement

May 2001

0.4 amp Schottky Low Forward Voltage Rectifier:

B0520WS -- First SOD-323 Rectifier Product

!
