AISC-0603-R0091 데이터시트(PDF) 1 Page - Abracon Corporation |
|
|
|||||||||||||||||||||||||||||
AISC-0603-R0091 데이터시트(HTML) 1 Page - Abracon Corporation |
|
|
1 / 4 page  • Ceramic construction assures the utmost thermal stability & high SRF • Exceptionally high Q compared to non-wirewound inductors, especially at high frequencies • Inductance options from 1.8nH to 560nH • Epoxy coating protects wound wire FEATURES: APPLICATIONS: ELECTRICAL SPECIFICATIONS: • Widely applied in VCO, SAW circuit for GSM, and CDMA communications AISC-0603 30332 Esperanza, Rancho Santa Margarita, California92688 tel 949-546-8000 | fax 949-546-8001| www.abracon.com Revised: 09.16.13 Visit www.abracon.com for Terms & Conditions of Sale CERAMIC WIRE WOUND INDUCTORS ABRACON IS ISO9001:2008 CERTIFIED 1.80 x 1.12 x 1.02mm Part Number AISC-0603- Inductance Code Inductance Tolerance Min. Quality Factor L/Q Test Freq. Max. DC Resistance Max. Rated Current Min. Self-resonant Frequency Units nH - - MHz Ω mA MHz Symbol L - Q Freq. DCR Ir S.R.F AISC-0603-R0018 1.8 C, S, D J, K 18 250 0.043 1000 > 6000 AISC-0603-R0027 2.7 C, S, D J, K 25 250 0.043 1000 > 6000 AISC-0603-R0033 3.3 C, S, D J, K 25 250 0.059 850 > 6000 AISC-0603-R0036 3.6 C, S, D J, K 25 250 0.059 850 > 6000 AISC-0603-R0039 3.9 C, S, D J, K 25 250 0.059 850 > 6000 AISC-0603-R0043 4.3 C, S, D J, K 25 250 0.059 850 > 6000 AISC-0603-R0047 4.7 C, S, D J, K 25 250 0.065 800 > 6000 AISC-0603-R0051 5.1 C, S, D J, K 21 250 0.130 600 > 6000 AISC-0603-R0062 6.2 C, S, D J, K 29 250 0.095 700 > 6000 AISC-0603-R0068 6.8 C, S, D, G, J, K 29 250 0.095 700 > 6000 AISC-0603-R0075 7.5 C, S, D, G, J, K 33 250 0.095 700 > 6000 AISC-0603-R0082 8.2 C, S, D, G, J, K 31 250 0.095 700 > 6000 AISC-0603-R0087 8.7 C, S, D, G, J, K 31 250 0.095 700 > 6000 AISC-0603-R0091 9.1 C, S, D, G, J, K 30 250 0.120 620 6000 AISC-0603-R0095 9.5 C, S, D, G, J, K 26 250 0.160 540 6000 AISC-0603-R010 10 C, S, D, G, J, K 30 250 0.130 600 6000 AISC-0603-R011 11 C, S, D, G, J, K 35 250 0.130 600 6000 AISC-0603-R012 12 C, S, D, G, J, K 35 250 0.130 600 6000 AISC-0603-R013 13 C, S, D, G, J, K 35 250 0.130 600 6000 AISC-0603-R015 15 C, S, D, G, J, K 37 250 0.150 550 6000 AISC-0603-R016 16 C, S, D, G, J, K 37 250 0.150 550 5500 AISC-0603-R018 18 C, S, D, G, J, K 37 250 0.150 550 5500 AISC-0603-R020 20 C, S, D, G, J, K 37 250 0.150 550 4900 AISC-0603-R022 22 C, S, D, G, J, K 38 250 0.190 490 4600 AISC-0603-R023 23 C, S, D, G, J, K 40 250 0.190 490 3800 AISC-0603-R024 24 C, S, D, G, J, K 40 250 0.190 490 3800 AISC-0603-R025 25 C, S, D, G, J, K 40 250 0.190 490 3700 AISC-0603-R027 27 C, S, D, G, J, K 38 250 0.190 490 3700 AISC-0603-R030 30 C, S, D, G, J, K 38 250 0.210 470 3300 AISC-0603-R033 33 C, S, D, G, J, K 40 250 0.210 470 3200 AISC-0603-R036 36 C, S, D, G, J, K 40 250 0.220 460 2900 AISC-0603-R039 39 C, S, D, G, J, K 40 250 0.220 460 2800 AISC-0603-R043 43 C, S, D, G, J, K 40 250 0.270 400 2700 AISC-0603-R047 47 C, S, D, G, J, K 36 200 0.270 400 2600 AISC-0603-R051 51 C, S, D, G, J, K 35 200 0.300 390 2400 AISC-0603-R056 56 C, S, D, G, J, K 38 200 0.350 360 2400 AISC-0603-R062 62 C, S, D, G, J, K 36 200 0.380 350 2300 RoHS/RoHS II Compliant |
