ADDR10 데이터시트(PDF) 32 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
ADDR10 데이터시트(HTML) 32 Page - List of Unclassifed Manufacturers |
|
|
32 / 68 page  T i mi ng Diag ram s 28 NS 75 20 Da ta shee t 03 /2 00 6 Timing Diagrams Timing_Specifications All timing specifications consist of the relationship between a reference clock and a signal: There are bussed and non–bussed signals. Non–bussed signals separately illustrate 0–to–1 and 1–to–0 transitions. Inputs have setup/hold times versus clock rising. Outputs have switching time relative to either clock rising or clock falling. Note: Timing relationships in this diagram are drawn without proportion to actual delay. Hold Setup time Valid from rising edge Valid from falling edge Hold time Setup time 1-to-0 from falling edge 0-to-1 from falling edge 1-to-0 from rising edge 0-to-1 from rising edge Clock Signal Bus |
|
