Cooper Bussmann

Description

Panasonic

Elna

KS-2R8334-R

0.33F, 2.8V SMT Coin Cell

DC-2R5ED224U-E (0.22F, 2.5V)

KS-3R3224-R

0.22F, 3.3V SMT Coin Cell

DCK-3R3ED224U-E

KSR-3R3204-R

0.2F, 3.3V SMT Low-Profile

EECEN0F204 Type RK

St. Louis, MO 63178

636-394-2877

www.cooperbussmann.com

Reorder # 4023

0708-5M

P r i nted in USA

Catalog Symbol:

PowerStor® KS Series

Supercapacitor Specifications

Series

Voltage Rating

RoHS Compliant

Capacitance Value

(10 x 104 µF = 0.1F)

Top View

Side View

Quick Cross Reference:

Package Styles and Dimensions - mm

PCB Layout (mm):

KS Series:

KS/

KSR Slim Line:

KSR-3R3 224 -R

9.5

6.1

2.1

2.5

0.6

0.8

0.85

Specifications

KSR

Working Voltage

2.8V

3.3V

Nominal Capacitance Range

0.33F

0.22F

0.2F

Maximum Equivalent Series Resistance @ 1kHz

100

200

Capacitance Tolerance

-20% to +80% (20°C)

Operating Temperature Range

-25°C to +70°C

-10°C to +60°C

Series

Diameter

Height

6.8

2.8

KSR (low-profile)

6.8

1.8

Order samples online - www.cooperbussmann.com

Cooper Bussmann PowerStor® supercapacitors are

unique, ultra-high capacitance devices utilizing

electrochemical double layer capacitor (EDLC)

construction combined with new, high performance

materials.

The PowerStor KS Series provides 2.8V and 3.3V

coin cell supercapacitors that combine small size

and ultra-low current leakage. These features make

the KS Series ideal for use in handheld and

portable battery-powered devices where space is

at a premium.

Typical Applications:

• Digital still cameras

• Portable data terminals

• GPS navigation

• MP3 players

• PDAs

• Solar watches and calculators

Packaging:

• KS Series - Bulk pack (1000 pieces per pack)

• KSR Series - Bulk pack (1000 pieces per pack)
