NCSS25-R010TRF datasheet(6/6 Pages) NIC

부품명	NCSS25-R010TRF

상세설명	Current Sensing Chip Resistors

PDF	6 Pages

Scroll/Zoom	100%

제조업체	NIC [NIC-Components Corp.]

홈페이지	http://www.niccomp.com

Logo

6 / 6 page

NIC COMPONENTS CORP. www.niccomp.com www.lowESR.com

www.RFpassives.com

www.SMTmagnetics.com

SPECIFICATIONS ARE SUBJECT TO CHANGE

Current Sensing Chip Resistors

NCSS Series

Case

Size

Quantity

per Reel

2010

2.8 ± 0.2

5.3 ± 0.2 0.85 ± 0.15 4.0 ± 0.05 4.0 ± 0.1 1.75 ± 0.1 5.5 ± 0.05

1.5 ± 0.1

1.5 min.

12.0 ± 0.2

4,000

2512 3.6 +02/

-0.18

6.9 ± 0.2 0.85 ± 0.15 4.0 ± 0.05 4.0 ± 0.1 1.75 ± 0.1 5.5 ± 0.05

1.5 +0.1/

-0

1.5 min.

12.0 ± 0.2

4,000

EMBOSSED PLASTIC TAPE DIMENSIONS (mm)

Case

Size

Quantity

per Reel

0805 1.6 ± 0.15 2.4 ± 0.2

0.84 ± 0.1

4.0 ± 0.1

4.0 ± 0.1 1.75 ± 0.1 3.5 ± 0.05

1.5 +0.1/

-0

8.0 ± 0.2

5,000

1206 2.0 ± 0.15 3.6 ± 0.2

0.84 ± 0.1

4.0 ± 0.1 4.0 ± 0.1 1.75 ± 0.1 3.5 ± 0.05

1.5 +0.1/

-0

8.0 ± 0.2

5,000

PAPER TAPE DIMENSIONS (mm)

Bottom

Tape

Top

Tape
