Dimensions are in inches [Dimensions in brackets are in millimeters].

performance information

Test Parameter

Description

Result

Qualification test suite

(TIA/EIA-568-B.3 requirements)

Complete testing protocol per TIA/EIA-568-B.3

using TIA/EIA FOTPs that include mechanical,

environmental and optical test sequences

Compliant; exceeds

TIA/EIA-568-B.3 requirements

Connector intermatability

Dimensional and material compliance to

TIA/EIA standards

All connectors are FOCIS compliant

with TIA/EIA-604-3

*All connector insertion loss values calculated from tests taken with precision launch jumper assemblies per TIA/EIA-FOTP-171.

selection information

Part Number

FSCMBL

Simplex

900µm buffered fiber and

3.0mm jacketed cable

FSCM5BL

Simplex

900 micron buffered fiber and

3.0mm jacketed cable

FSCDM5BL

Duplex

FSCM2.05BL

Simplex

900 micron buffered fiber and

1.6 – 2.0mm jacketed cable

FSCMRD

Simplex

900µm buffered fiber and

3.0mm jacketed cable

FSCM2.0BL

Simplex

900µm buffered fiber and

1.6mm – 2.0mm jacketed cable

FSCM2.0RD

Simplex

900µm buffered fiber and

1.6mm – 2.0mm jacketed cable

FSCDM

Duplex

3.0mm jacketed cable

3.0mm jacketed cable

FSCSBU

Simplex

900µm buffered fiber and

3.0mm jacketed cable

FSCS2.0BU

Simplex

900µm buffered fiber and

1.6mm – 2.0mm jacketed cable

Connector

Type

Cable Type

Fiber

Ferrule

Housing

Color

Boot

Color

Return

Loss

Average

Insertion Loss*

Multimode

Zirconia

Ceramic

Electric

Ivory

Black

Black

Black

Red

Red

Red and

Black

>20

0.1dB

Singlemode

Zirconia

Ceramic

Blue

Blue

>40

0.15dB

SC Fiber Optic Connectors

2.20 [55.9]

2.20 [55.9]

SC Simplex Connectors

For 900µm Fiber and 3.0mm Jacketed Cable

For 3.0mm Jacketed Cable

SC Duplex Connector

2.20

[55.9]

FSCMBL, FSCM5BL, FSCMRD, FSCSBU

FSCDM, FSCDM5BL

1.93 [49.0]

1.93 [49.0]

For 900µm Fiber and 1.6mm – 2.0mm Jacketed Cable

FSCM2.0BL, FSCM2.05BL, FSCM2.0RD, FSCS2.0BU
