QBLP651 Series
1206 LED with Inner Lens
---------------------------------------------------------------------------------------------------------------------------------------
Product: QBLP651_series
Date: October 16, 2014
Page 4 of 14
Version# 1.2
Electrical / Optical Characteristic (T=25
oC)
Product Number
Color
IF(mA)
VF(V)
λD (nm)
Iv(mcd)
Min
Typ. Max Min.
Typ. Max.
Min.
Typ.
QBLP651-IW
White
20
2.8
3.2
3.7
x: .25
y: .24
--
x: .33
y: .34
160
320
QBLP651-IB
Blue
20
2.8
3.1
3.7
465
470
475
320
550
QBLP651-IG
True Green
20
2.8
3.4
3.7
520
525
530
1600
2700
QBLP651-R
Red
20
1.7
2.0
2.5
615
620
630
320
600
QBLP651-AG
Yellow Green
20
1.7
2.0
2.5
565
--
576
80
150
QBLP651-Y
Yellow
20
1.7
2.0
2.5
585
590
595
320
660
QBLP651-O
Orange
20
1.7
2.0
2.5
600
605
610
200
450
Absolute Maximum Rating
Material
Pd (mW)
IF (mA)
IFP (mA)*
VR (V)
TOP (
oC)
TST (
oC)
TSOL (
oC)**
AlInGaP
75
30
125
5
-40 to +80
-40 to +85
260
InGaN
111
30
125
5
-40 to +80
-40 to +85
260
*Duty 1/8 @ 1KHz
** IR Reflow for no more than 10 sec @ 260
oC
Forward Voltage VF for AlInGaP @ IF=20mA
Bin
Min.
Max.
Unit
□
1.7
2.5
V
Forward Voltage VF for InGaN @ IF=20mA
Bin
Min.
Max.
Unit
f
2.8
3.1
V
g
3.1
3.4
h
3.4
3.7
