QBLP653R_series
1208 LED
Product: QBLP653R_series
Date: February 16, 2012
Page 1 of 12
Version# 1.1
Feature:
 Water clear lens
 Package in tap and reel
 Reverse mount package
 Bright 1208 LED package
 InGaN technology for IB/IG/IW
 AllnGaP technology for R/AG/Y/O
 15°Viewing Angle (R/AG/Y/O/IB/IG)
 130°Viewing Angle (IW)
Description:
This reversed mount light weight bright 1208 LEDs
have a height profile of 2.5mm. With narrow viewing
angle, LED produces high bright light output.
Application:
 Status indication
 Back lighting application
Certification & Compliance:
 TS16949
 ISO9001
 RoHS Compliant
Dimension:
Units: mm / tolerance = +/-0.1mm
