QBLP655 series

1205 LED

------------------------------------------------------------------------------------------------------------------------------------------

Product: QBLP655 series

Date: March 27, 2014

Page 3 of 13

Version# 2.1

Introduction

Feature:

 Water clear lens

 Package in tape and reel

 Ultra bright 1205 package

 InGaN technology for IB/IG/IW

 AlInGaP technology for R/AG/ Y/O

 Viewing angle: 140 degrees

Description:

These ultra-bright 655 LEDs have a height profile of

1.10mm. With a combination of high brightness output

and small footprint, these LEDs are ideal for keypad

backlighting and status indication.

Application:

 Status indication

 Back lighting application

Certification & Compliance:

 TS16949

 ISO9001

 RoHS Compliant

Dimension:

Units: mm / tolerance = +/-0.1mm
