Power Chip High Current Inductors

PCHC40

All specifications subject to change without notice.

Features

• Designed for high current, low voltage

DC to DC converter applications

• Current ratings up to 16Arms and

saturation current up to 20A

• Extremely low DCR

• Provided in tape and reel packaging for

pick and place assembly

Electrical

Inductance Range: .33

µh to 100µh.

Tolerance:

± 20% over the entire

inductance range.

Test Frequency: Inductance measured

at 100KHz, 0.1 Vrms. After soldering, push

Operating Temp. Range: i-40

° to +85°C.ll

Inductance Drop: 10% typically at the

rated Isat.0 to 2000) x 10 -6

°C.

Physical

Packaging: 700 pieces per 13 inch reel.

Allied

Part

Number

Inductance

(

µh)

Irms

(A)

SRF

Reference

(MHz)

Tolerance

(%)

DCR

Max.

(

Ω)

PCHC40-R33M-RC

PCHC40-R68M-RC

PCHC40-1R0M-RC

PCHC40-1R5M-RC

PCHC40-2R2M-RC

PCHC40-2R7M-RC

PCHC40-3R3M-RC

PCHC40-4R7M-RC

PCHC40-6R8M-RC

PCHC40-100M-RC

PCHC40-150M-RC

PCHC40-220M-RC

PCHC40-330M-RC

PCHC40-470M-RC

PCHC40-680M-RC

PCHC40-101M-RC

Isat

(A)

.33

.68

1.0

1.5

2.2

2.7

3.3

4.7

6.8

10

15

22

33

47

68

100

.002

.005

.006

.008

.011

.012

.014

.018

.035

.04

.06

.08

.15

.28

.3

.4

20

300

200

100

90

65

45

35

26

21

17

14

12

9

7

20.0

13.0

11.0

9.0

7.8

7.0

6.4

5.4

3.6

3.3

2.4

2.0

1.7

1.4

1.2

.95

16.0

12.0

10.0

9.0

7.4

6.6

5.9

4.8

5.0

4.3

3.5

2.8

2.1

1.7

1.5

1.2

ALLIED COMPONENTS INTERNATIONAL

714-665-1140

www.alliedcomponents.com

RoHS

0.520

(13.21)

MAX.

0.390

(9.91)

MAX.

0.120

(3.05)

0.330

(8.38)

0.250

(6.35)

MAX.

0.340

(8.64)

0.060

(1.52)

0.160

(4.06)

Dimensions:

Inches

(mm)

Temperature Rise: T=40ºC rise

∆

typical at Irms.

REVISED 10/9/09
