Fixed Inductors (Chip Inductors)

1

10

100

1000

10

100

1000

10000

20

40

60

80

100

120

10

100

1000

10000

2N2

10N

22N

47N

R22

R10

4N7

2N2

R22

R10

47N

22N

Frequency (MHz)

Frequency (MHz)

● Q-Frequency Characteristics (Typ.)

Part No

Inductance (nH)(Typ.)

Q(Typ.)

800MHz 900MHz

1.8GHz

2.0GHz

2.4GHz

800MHz 900MHz

1.8GHz

2.0GHz

2.4GHz

ELJRE1N0

□FA

1.01

1.01

0.99

0.98

0.98

71.2

76.8

116.8

129.6

155.8

ELJRE1N2

□FA

1.19

1.19

1.18

1.17

1.17

65.1

69.8

102.7

113.9

136.9

ELJRE1N5

□FA

1.41

1.41

1.39

1.39

1.38

52.7

56.2

79.6

88.0

103.3

ELJRE1N8

□FA

1.86

1.86

1.84

1.84

1.84

55.9

59.6

86.7

97.5

117.0

ELJRE2N2

□FA

2.10

2.09

2.07

2.07

2.07

48.6

51.3

74.8

83.6

98.6

ELJRE2N7

□FA

2.59

2.59

2.58

2.59

2.60

48.6

51.3

71.1

78.1

89.9

ELJRE3N3

□FA

3.09

3.08

3.08

3.09

3.11

49.6

52.7

78.5

88.6

105.8

ELJRE3N9

□FA

3.61

3.61

3.63

3.65

3.69

50.2

53.0

70.5

77.1

87.0

ELJRE4N7

□FA

4.42

4.42

4.48

4.52

4.60

46.3

49.4

69.4

76.6

86.1

ELJRE5N6

□FA

5.39

5.39

5.49

5.55

5.66

49.5

52.8

75.4

84.0

94.3

ELJRE6N8

□FA

6.59

6.60

6.79

6.89

7.08

49.3

52.8

78.1

86.7

97.0

ELJRE8N2

□FA

7.97

7.99

8.33

8.51

8.83

49.0

52.4

75.4

82.6

89.1

ELJRE10N

□FA

9.60

9.63

10.22

10.51

11.07

44.2

47.0

63.4

68.0

69.7

ELJRE12N

□FA

11.7

11.8

12.7

13.2

14.1

44.6

47.7

64.7

68.5

67.8

ELJRE15N

□FA

14.6

14.6

16.2

17.1

18.7

42.4

45.4

58.4

59.5

56.9

ELJRE18N

□FA

17.6

17.8

20.2

21.5

24.2

45.9

49.4

64.6

65.0

58.8

ELJRE22N

□FA

21.7

21.9

26.0

28.3

33.3

43.0

45.8

54.2

52.2

43.8

ELJRE27N

□FA

27.2

27.6

34.6

38.9

49.3

43.9

47.0

52.4

49.2

38.1

ELJRE33N

□FA

33.3

33.9

45.5

53.2

75.2

41.8

44.4

45.2

39.3

26.2

ELJRE39N

□FA

39.8

40.7

58.6

71.9

117.0

42.2

44.9

40.4

33.1

18.8

ELJRE47N

□FA

48.3

49.6

79.8

107.1

260.7

42.6

45.3

34.1

24.0

8.8

ELJRE56N

□FA

59.2

61.1

112.8

176.3

735.5

42.0

44.5

25.1

15.2

0.8

ELJRE68N

□FA

73.9

77.0

185.9

459.7

41.8

44.0

21.5

9.5

ELJRE82N

□FA

94.0

99.6

494.3

39.7

41.5

7.7

ELJRER10

□FA

115.2

123.5

2141.2

35.3

36.7

1.6

ELJRER12

□FA

143.4

156.9

35.2

35.7

ELJRER15

□FA

188.5

210.6

40.6

41.5

ELJRER18

□FA

242.9

280.4

39.0

39.8

ELJRER22

□FA

337.9

416.6

43.2

45.3

□ : Symbol of Tolerance
