HSM276AS
2
Absolute Maximum Ratings (Ta = 25
°C)
Item
Symbol
Value
Unit
Repetitive peak reverse
voltage
V
RRM
5V
Reverse voltage
V
R
3V
Average rectified current
I
O
*
30
mA
Junction temperature
Tj
125
°C
Storage temperature
Tstg
-55 to +125
°C
Note
: Per one device
Electrical Characteristics (Ta = 25
°C) *2
Item
Symbol
Min
Typ
Max
Unit
Test Condition
Reverse voltage
V
R
3.0
—
—
V
I
R = 1 mA
Reverse current
I
R
——
50
µAV
R = 0.5V
Forward current
I
F
35
—
—
mA
V
F = 0.5V
Capacitance
C
—
—
0.90
pF
V
R = 0.5V, f = 1 MHz
Capacitance deviation
∆ C
—
—
0.10
pF
V
R = 0.5V, f = 1 MHz
ESD-Capability
*1
—
30
—
—
V
C=200pF , R = 0
Ω
Both forward and reverse direction 1pulse.
Notes
: 1. Failure criterion ; I
R ≥ 100 µA at VR =0.5 V
2. Per one device
