SMD Type
www.kexin.com.cn
2
Transistors
NPN Transistors
2SC3906K
■
Typical Characterisitics
0.1
1
10
0
0.5
1
1.5
2
Ta=－40ºC
25ºC
100ºC
VCE= 6V
10
100
1000
0.1
1
10
100
Ta=100ºC
25ºC
－
40ºC
VCE= 6V
10
100
1000
0.1
1
10
100
VCE= 5V
3V
1V
Ta=25ºC
Fig.1 Ground Emitter Propagation Characteristics
BASE TO EMITTER VOLTAGE : VBE [V]
Fig.2 Typical Output Characteristics
COLECTOR TO EMITTE VOLTAGE : VCE [V]
Fig.3 DC Current Gain vs. Collector Current(I)
COLLECTOR CURRENT : IC [mA]
Fig.4 DC Current Gain vs. Collector Current(II)
COLLECTOR CURRENT : IC [mA]
