Data Sheet G11024EJ6V0DS00
8
µµµµPC1663
APPLICATION CIRCUIT EXAMPLES
EXAMPLE 1
Video Line Driver Circuit Example
Input
75
Ω
75
Ω
200
Ω
Output
75
Ω
75
Ω
COAXIAL
200
Ω
–6 V
+6 V
0.1 F
µ
µPC1663
2.0
1.0
0
100 k
1 M
10 M
Frequency f (Hz)
MAXIMUM OUTPUT VOLTAGE vs. FREQUENCY (VIDEO LINE, SINGLE-ENDED)
PHASE CHARACTERISTICS vs. FREQUENCY
100 M
1 G
100 k
0
–45
–90
–135
–180
1 M
10 M
Frequency f (Hz)
100 M
Gain 1
Gain 2
VCC±
=
±6 V
VCC± =
±6 V
Remark
Differential output voltage is double of single-ended output voltage.
