1 / 2 page

DIP Type

www.kexin.com.cn

1

Transistors

■

Features

●

High Current Gain Bandwidth Product : fT=1100MHz

●

Output Capacitance : COB=1.5pF (MAX.)

0.46± 0.10

1.27TYP

(R2.29)

[1.27± 0.20]

1.27TYP

[1.27± 0.20]

3.60± 0.20

4.58 +0.25

–0.15

0.38

+0.10

–0.05

TO-92

1. Emitter

3. Base

2. Collector

Unit: mm

1 2 3

■

Absolute Maximum Ratings Ta = 25℃

Parameter

Symbol

Rating

Unit

Collector - Base Voltage

VCBO

30

Collector - Emitter Voltage

VCEO

15

Emitter - Base Voltage

VEBO

5

Collector Current - Continuous

IC

50

mA

Collector Power Dissipation

PC

250

mW

Junction Temperature

TJ

150

Storage Temperature Range

Tstg

-55 to 150

V

℃

■

Electrical Characteristics Ta = 25℃

Parameter

Symbol

Test Conditions

Min

Typ

Max

Unit

Collector- base breakdown voltage

VCBO

Ic= 100 μA， IE= 0

30

Collector- emitter breakdown voltage

VCEO

Ic= 5 mA， IB= 0

15

Emitter - base breakdown voltage

VEBO

IE= 100μA， IC= 0

5

Collector-base cut-off current

ICBO

VCB= 30 V , IE= 0

0.1

Emitter cut-off current

IEBO

VEB= 5V , IC=0

0.1

Collector-emitter saturation voltage

VCE(sat) IC=10 mA, IB=1mA

0.5

Base - emitter saturation voltage

VBE(sat) IC=10 mA, IB=1mA

1.2

DC current gain

hFE

VCE= 10V, IC= 5mA

40

240

Collector output capacitance

Cob

VCB= 10V, IE= 0,f=1MHz

1.5

pF

Collector-Base Time Constant

Cc-rbb'

VCE= 10V, IE= 5mA,f=31.9MHz

10

20

ps

Transition frequency

fT

VCE= 10V, IC= 5mA

800 1100

MHz

V

uA

■

Classification of hfe

Type

KSC1730-R

KSC1730-O

KSC1730-Y

Range

40-80

70-140

120-240

NPN Transistors

KSC1730-HF

●

Pb−Free Package May be Available. The G−Suffix Denotes a

Pb−Free Lead Finish
