background image
DATA SHEET
SEMICONDUCTOR
http://www.yeashin.com
1
REV.03 20140320
YSDAxx11CDN
H
APPLICATIONS
◆ Cell Phone Handsets and Accessories
◆ Microprocessor based equipment
◆ Personal Digital Assistants (PDA’s)
◆ Notebooks, Desktops, and Servers
◆ Portable Instrumentation
◆ Peripherals
◆ Pagers
IEC COMPATIBILITY
◆ IEC61000-4-2 (ESD) ±30kV (air), ±30kV (contact) : 3.3V ~ 15V
◆ IEC61000-4-2 (ESD) ±15kV (air), ±8kV (contact) : 18V ~ 36V
◆ IEC61000-4-4 (EFT) 40A (5/50ηs)
FEATURES
◆ 200 Watts Peak Pulse Power per Line (tp=8/20µs)
◆ Protects One Bidirectional I/O Line
◆ Low clamping voltage
◆ Working voltages : 3.3V ~ 36V
◆ Low leakage current
MECHANICAL CHARACTERISTICS
◆ DFN1006DN (1.0x0.6x0.5mm) Package
◆ Molding Compound Flammability Rating : UL 94V-O
◆ Weight 0.5 Millgrams (Approximate)
◆ Quantity Per Reel : 10,000pcs
◆ Reel Size : 7 inch
◆ Lead Finish : Lead Free
DFN1006DN
PIN CONFIGURATION
BIDIRECTIONAL TVS DIODE
