ISM band and 3G Cellular Omni-directional Antenna

Picture of the Antenna

Application

The WPANTDP067-R1A is a high gain Omni-directional Pole mount antenna. It comes with an N-type female

connector and appropriate mounting hardware. The antenna is at DC ground to ensure protection against lightning.

WP Wireless can assist your engineers to optimize mounting positions for these antennas in your specific application

and can further customize the antennas for your specific needs. Please contact sales@wp-wireless.com with your

specific application requirements.

Electrical Properties

Parameter

Antenna Performance

Operating Frequency

900-930 MHz

806

– 960 MHz

1710

– 1990 MHz

Recommended

Impedance of the

customer Radio

Module[

]

50Ω

50Ω

50Ω

VSWR - Typical

<2:1

<2:1

<2:1

Peak Gain [dBi]

(Typical)

7 dBi

7 dBi

9 dBi

Polarization

Vertical

Vertical

Vertical

Pattern

Omni-Directional

Omni-Directional

Omni-Directional

Accepted Power [W]

(Max)

40 Watts

40 Watts

40 Watts

Lightning Protection

DC ground

DC ground

DC ground
