WPANTDP069-R1A 데이터시트(PDF) 2 Page - World Produts Inc.

부품명 WPANTDP069-R1A
상세설명  The WPANTDP069-R1A antenna is an L1 band GPS and FM Dual Antenna for automobile applications
PDF  2 Pages
Scroll/Zoom Zoom In 100%  Zoom Out
제조업체  WPI [World Produts Inc.]
홈페이지  http://www.worldproducts.com
Logo WPI - World Produts Inc.

WPANTDP069-R1A 데이터시트(HTML) 2 Page - World Produts Inc.

  WPANTDP069-R1A Datasheet HTML 1Page - World Produts Inc. WPANTDP069-R1A Datasheet HTML 2Page - World Produts Inc.
Zoom Inzoom in Zoom Outzoom out
 2 / 2 page
background image
WP Wireless — A Division of World Products LLC. || 19656 Eighth Street East || Sonoma, CA, 95476, USA
[O]: +1-707-996-5201 || [F]: +1-707-996-3380 || [E]: sales@wp-wireless.com || [W]: www.wp-wireless.com
Page 2 of 2
Rev: 1.0
Created on: Oct. 15
th 2012
Created by: MKS
Approved By: BP
WPANTDP069-R1A
Automotive GPS & FM Dual band Antenna
Mechanical / Environmental Properties
Item
Value
Total Antenna Dimensions
383.5mm (Length) x 25.7mm (Width at the base)
Antenna Color
Black
Cable
GPS: 1755mm RG-316-U / FM: 1755mm RG-188-A/U
Connector
GPS: FAKRA / FM: DIN41585
Operating / Storage Temperature
-40
oC to +90oC
Environmental
Meets standards for UL 94V-0
Hazardous Materials
RoHS compliant
Picture of the Antenna
