 2 / 3 page
background image
DIMENSIONS
Min
Max
Min
Max
A
1.15
1.25
0.05
0.05
B
0.75
0.85
0.03
0.03
C
0.15
0.27
0.01
0.01
D
E
1.15
1.25
0.05
0.05
F
0.43
0.55
0.02
0.02
G
0.15
0.25
0.01
0.01
H
0.25
0.37
0.01
0.01
MARKING
PART NO.
MARKING
2SA2029-Q
FQ
2SA2029-R
FR
2SA2029-S
FS
Document Number: DS_S1402005
Version: A14
ORDER INFORMATION (EXAMPLE)
DIM.
Unit (mm)
Unit (inch)
0.8 TYP.
0.031 TYP.
SOT-723
2SA2029-Q/R/S
Taiwan Semiconductor
Small Signal Product
2SA2029‐QRMG
Green compound code
Packing code
Part no.
B
A
C
D
G
F
E
H
