 2 / 9 page
background image
17.08.2010
led395_series.doc
2 of 9
● Characteristics of Radiant Intensity [Ta=25°C]
Radiant Intensity IF= 20mA [mW/sr]
Type
Viewing
Half Angle
Minimum
Typical
Maximum
Outer
Dimension
Dimension
Figure
LED395-01
± 8°
45
Ø 5
1
LED395-02
± 5°
55
Ø 5
2
LED395-03
± 10°
45
Ø 5
3
LED395-04
± 20°
18
Ø 5
4
LED395-05
± 50°
5
Ø 5
5
LED395-06
± 4°
Ø 5
6
± 25°
(Long)
Ø 5
LED395-09
± 10°
(Short)
Oval
7
LED395-46
Ø 5
8
LED395-41
± 14°
Ø 4
9
LED395-42
± 20°
Ø 4
10
LED395-31
Ø 3
11
LED395-33
± 13°
16
Ø 3
12
LED395-34
Ø 3
13
LED395-36
± 25°
7
Ø 3
14
► Radiated Power is measured by S3584-08.
