M30620FCAFP 데이터시트(PDF) 65 Page - Mitsubishi Electric Semiconductor |
|
|
|||||||||||||||||||||||||||||
M30620FCAFP 데이터시트(HTML) 65 Page - Mitsubishi Electric Semiconductor |
|
|
65 / 274 page  Mitsubishi microcomputers M16C / 62A Group SINGLE-CHIP 16-BIT CMOS MICROCOMPUTER Watchdog Timer 65 Watchdog timer control register Symbol Address When reset WDC 000F16 000XXXXX2 Function Bit symbol W R b7 b6 b5 b4 b3 b2 b1 b0 High-order bit of watchdog timer WDC7 Bit name Prescaler select bit 0 : Divided by 16 1 : Divided by 128 Watchdog timer start register Symbol Address When reset WDTS 000E16 Indeterminate W R b7 b0 Function The watchdog timer is initialized and starts counting after a write instruction to this register. The watchdog timer value is always initialized to “7FFF16” regardless of whatever value is written. Reserved bit Reserved bit Must always be set to “0” Must always be set to “0” 0 0 Figure 1.12.2. Watchdog timer control and start registers |
|
