S 1560C VER 3

M/A-COM

n North America: Tel. (800) 366-2266, Fax (800) 618-8883 n Asia/Pacific: Tel.+85 2 2111 8088, Fax +85 2 2111 8087 n

Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020

www.macom.com

Specifications subject to change without notice.

Low Cost Two-Way SMT Power Divider 1920– 2170 MHz

DS52-0002

1. Exceeding these limits may cause permanent damage.

Absolute Maximum Ratings

1

Parameter

Absolute Maximum

Input Power²

1 W CW

Operating Temperature

-40°C to +85°C

Storage Temperature

-65°C to +150°C

Recommended PCB Configuration

(Dimensions in Inches)

Functional Diagram ³

2. With Internal load dissipation of 0.125 W maximum.

PHASE BALANCE VS FREQUENCY

RELATIVE TO RF1

0.00

1.00

2.00

3.00

1920.00

1970.00

2020.00

2070.00

2120.00

2170.00

Frequency (MHz)

ISOLATION VS FREQUENCY

-40.00

-35.00

-30.00

-25.00

-20.00

-15.00

1920.00

1970.00

2020.00

2070.00

2120.00

2170.00

Frequency (MHz)

INSERTION LOSS VS FREQUENCY

-1.00

-0.80

-0.60

-0.40

-0.20

0.00

1920.00

1970.00

2020.00

2070.00

2120.00

2170.00

Frequency (MHz)

VSWR VS FREQUENCY

1.00

1.20

1.40

1.60

1.80

2.00

1920.00

1970.00

2020.00

2070.00

2120.00

2170.00

Frequency (MHz)
