S 1561B VER 3

M/A-COM Division of AMP Incorporated

n North America: Tel. (800) 366-2266, Fax (800) 618-8883 n Asia/Pacific: Tel.+85 2 2111 8088,

Fax +85 2 2111 8087

n Europe: Tel. +44 (1344) 869 595, Fax+44 (1344) 300 020

www.macom.com

AMP and Connecting at a Higher Level are trademarks.

Specifications subject to change without notice.

Low Cost Two-Way SMT Power Divider 1510-1660 MHz

DS52-0004

1. Exceeding these limits may cause permanent damage.

Absolute Maximum Ratings

1

Parameter

Absolute Maximum

Input Power²

1 W CW

Operating Temperature

-40°C to +85°C

Storage Temperature

-65°C to +150°C

Functional Diagram ³

2. With Internal load dissipation of 0.125 W maximum.

Recommended PCB Configuration

(Dimensions in Inches)

Phase Balance Vs Frequency

-1

-0.8

-0.6

-0.4

-0.2

0

1510

1547.5

1585

1622.5

1660

MHz

Isolation Vs Frequency

-26

-24

-22

-20

-18

-16

-14

1510

1547.5

1585

1622.5

1660

MHz

Insertion loss Vs Frequency

-1

-0.8

-0.6

-0.4

-0.2

0

1510

1547.5

1585

1622.5

1660

MHz

VSWR Vs Frequency

0

0.4

0.8

1.2

1.6

2

1510

1547.5

1585

1622.5

1660

MHz
