1 / 5 page

46 Warshavskoe shosse. Moscow 115230 Russia, ph: +7-499-678-2082, fax: +7-499-678-2083, web: www.rmtltd.ru

Page " of "

1

5

Sensitivity Se

μV/(W/m2)

22

Integral sensitivity Sa

V/W

0.34

Heat Flux Range Pe

±W/m2

8 500

Integral Heat Flux Range Pa

±W

0.55

Thermal Time Constant

s

1.6

Thermal Resistance RT

K/(W/m2)

1.20E-03

Integral Thermal Resistance RT

K/W

19.3

The HFD04-059-05L08 – high sensitive and self-

calibrating sensor of conduction, convection and

radiation heat ﬂuxes

in a wide range of heat ﬂux

intensities. Compatible with RMT Datalogger DX8140.

Thermoelectric Heat Flux Sensor

Dimensions (mm)

Thermoelectric Solutions

HTD 04-059-08D12

HFD04-059-05L08

- Ultra-High Sensitivity

- Miniature Dimensions

- Self-calibrating

- FET cable

- Phoenix Connector
