2 / 2 page

www.advantech.com/products

Online Download

Dimensions

Unit: mm [inch]

FPM-3171G

Diameters of the rackmount holes:

Vertical: 6.5 mm

Horizontal: 9 mm

I/O View

Panel Cut-out Dimensions: FPM-3171G: 447.5 x 329.5 mm (17.62" x 12.97")

VGA Port

DC-Jack 12VDC for

Power Adapter

Phoeni x Jack: 24 VDC

T/S USB Port

DVI-D

T/S RS-232 Port

445.20 (17.52”)

482.00 (18.98”)

63.50 (2.50”)

224.00 (8.82”)

100.00 (3.94”)

75.00

(2.95”)

465.00 (18.31”)

7.00

(0.27”)

432.91

(17.04”)

151.00

(5.94”)

37.50

(1.47”)

Ordering Information

FPM-3171G-X0AE

17" SXGA WT Ind. Monitor with VGA, DVI

FPM-3171G-R3AE

17"SVGA WT Ind. Monitor w/Resistive TS (Combo)

Accessories

1702002600

Power Cable US Plug 1.8 M

1702002605

Power Cable EU Plug 1.8 M

1702031801

Power Cable UK Plug 1.8 M

1700000596

Power Cable China/Australia Plug 1.8 M

(Direct rack mounting, no need accessory)
