LOW-POWER CK420BQ DERIVATIVE FOR PCIE COMMON CLOCK ARCHITECTURES

22

REVISION B 03/06/15

932SQL450 DATASHEET

Ordering Information

"LF" suffix to the part number are the Pb-Free configuration and are RoHS compliant.

“B” is the device revision designator (will not correlate with the datasheet revision).

Revision History

Part / Order Number

Shipping Packaging

Package

Temperature

932SQL450BGLF

Tubes

64-pin TSSOP

0 to +70° C

932SQL450BGLFT

Tape and Reel

64-pin TSSOP

0 to +70° C

932SQL450BKLF

Tray

64-pin VFQFPN

0 to +70° C

932SQL450BKLFT

Tape and Reel

64-pin VFQFPN

0 to +70° C

Rev.

Issue Date

Who Description

Page #

A

3/5/2014

RDW

1. Updated electrical table format and data to final.

2. Updated TEST_SEL pin description and TEST CLARIFICATION

TABLE to indicate that this input is a low threshold input.

3. Updated TEST LOADS and added ALTERNATE TERMINATIONS

diagrams.

4. Updated block diagram to latest format and updated pin names to

match the pinout.

5. Updated front page text to latest format

6. Move to Final.

Various

B

3/6/2015

RDW

1. Corrected typo in Powerdown Current max limit. Max limit changed

from 9mA to 10mA.

13
