1 / 3 page  UNISONIC TECHNOLOGIES CO., LTD UTT120P06 Preliminary Power MOSFET www.unisonic.com.tw 1 of 3 Copyright © 2014 Unisonic Technologies Co., Ltd QW-R502-728.b 120A, 60V P-CHANNEL POWER MOSFET DESCRIPTION The UTC UTT120P06 is a P-channel power MOSFET using UTC’s advanced technology to provide the customers with high switching speed and a minimum on-state resistance. It can also withstand high energy in the avalanche. The UTC UTT120P06 is suitable for low voltage and high speed switching applications FEATURES * RDS(ON) ≤ 6.9mΩ @ VGS = -10V * High Switching Speed SYMBOL ORDERING INFORMATION Ordering Number Package Pin Assignment Packing Lead Free Halogen Free 1 2 3 UTT120P06L-TA3-T UTT120P06G-TA3-T TO-220 G D S Tube UTT120P06L-TQ2-T UTT120P06G-TQ2-T TO-263 G D S Tube UTT120P06L-TQ2-R UTT120P06G-TQ2-R TO-263 G D S Tape Reel Note: Pin Assignment: G: Gate D: Drain S: Source MARKING INFORMATION PACKAGE MARKING TO-220 TO-263 |
