background image
IRMCF341
21
7.5
GATEKILL to SVPWM AC Timing
Unless specified, Ta = 25˚C.
Symbol
Parameter
Min
Typ
Max
Unit
twGK
GATEKILL pulse width
32
-
-
SYSCLK
tdGK
GATEKILL to PWM
output delay
-
-
100
SYSCLK
Table 12.
GATEKILL to SVPWM AC Timing
7.6
Interrupt AC Timing
Unless specified, Ta = 25˚C.
Symbol
Parameter
Min
Typ
Max
Unit
twINT
INT0, INT1 Interrupt
Assertion Time
4
-
-
SYSCLK
tdINT
INT0, INT1 latency
-
-
4
SYSCLK
Table 13.
Interrupt AC Timing
