L16B45
Preliminary
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
6 of 11
www.unisonic.com.tw
QW-R102-059.c
SWITCHING ELECTRICAL CHARACTERISTICS (VDD=3.3V)
PARAMETER
SYMBOL
TEST CONDITIONS
MIN
TYP
MAX
UNIT
CLK- OUTn
tpLH1
80
100
ns
LE- OUTn
tpLH2
80
100
ns
OE - OUTn
tpLH3
115
135
ns
Propagation Delay
Time (“L” to “H”)
CLK-SDO
tpLH
20
40
ns
CLK- OUTn
tpHL1
100
120
ns
LE- OUTn
tpHL2
80
100
ns
OE - OUTn
tpHL3
115
135
ns
Propagation Delay
Time (“H” to “L”)
CLK-SDO
tpHL
20
40
ns
CLK
tw(CLK)
20
ns
LE
tw(L)
20
ns
Pulse Width
OE
tw(OE)
300
100
ns
Hold Time for LE
th(L)
5
ns
Setup Time for LE
tsu(L)
VDD=3.3V, VDS=1.0V, VIH=VDD,
VIL=GND
Rext=930Ω, VL=3.0V, RL=100Ω,
CL=10pF
5
ns
Maximum CLK Rise Time
tr
500
ns
Maximum CLK Fall Time
tf
500
ns
Output Rise Time of IOUT
tor
160
180
ns
Output Fall Time of IOUT
tof
70
90
ns
