US2175
CMOS IC
UNISONICTECHNOLOGIESCO.,LTD
5 of 10
www.unisonic.com.tw
QW-R502-403.C
TEST CIRCUITS
(1)
RFG
VFLG
S1
VOUT
RL IL
COUT
+
A
IOUT
VOUT
GND
CTL
FLG
IN
CIN +
VIN
VCE
(2)
(3)
VOUT
GND
CTL
FLG
IN
+
VIN
CIN
V
+
COUT
IOUT
VRDS(ON)
VCE
(4)
GND
CTL
IN
VCE
+
VIN
CIN
VOUT
FLG
VOUT
RL IL
COUT
+
VFLG
RFG
(5)
Note: Above test circuits reflected the graphs shown on “Typical Characteristics” are as follows:
(1) On-State Supply Current vs. Input Voltage & Temperature, Off-State Supply Current vs. Input Voltage & Temperature
(2) Flag Trigger & Release Response, Inrush Current at Start-up
(3) Ramped Load Response, Short-Current Response at Start-up
(4) Thermal Shutdown Response, Turn off Response, Turn on Response
(5) Short Circuit Current Response, Ramped Load Response, Thermal Shutdown Response
