M2115

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 4

www.unisonic.com.tw

QW-R105-021.C



ABSOLUTE MAXIMUM RATINGS (TA=25C, unless otherwise specified)

PARAMETER

SYMBOL

RATINGS

UNIT

Supply Voltage

+/V-

±7.0

Differential Input Voltage

VI(DIFF)

±14

DIP-8

500

SOP-8

300

Power Dissipation

TSSOP-8

250

Operating Temperature

TOPR

-40 ~ +85

C

Storage Temperature

TSTG

-40 ~ +125

C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



ELECTRICAL CHARACTERISTICS (V+/V- =±2.5V, TA=25C, unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITION

MIN

TYP

MAX

UNIT

Input Offset Voltage

VI(OFF)

Rs≤10kΩ

Input Bias Current

II(BIAS)

100

300

Operating Current

ICC

VIN=0,RL=∞

3.5

Maximum Output Voltage Swing

VOM

RL≥2.5kΩ

±2

±2.2

Input Common Mode Voltage Range

VICM

±1.5

Large Signal Voltage Gain

RL≥10kΩ

Common Mode Rejection Ratio

CMRR

Supply Voltage Rejection Ratio

SVR

Slew Rate

VIN=±1V, GV=1

V/μs

Gain Bandwidth product

f=10kHz

MHz

Notes: 1. Applied circuit voltage gain is desired to be operated within the range of 3dB to 30dB.2. Repetitive Rating :

Pulse width limited by TJ.

2. Special care being required for input common mode voltage range and the oscillation due to the capacitive

load when operating follower.
