CONMCX012-R178 데이터시트(PDF) 1 Page - List of Unclassifed Manufacturers |
|
|
|||||||||||||||||||||||||||||
CONMCX012-R178 데이터시트(HTML) 1 Page - List of Unclassifed Manufacturers |
|
|
1 / 1 page  A B C D 4 3 2 1 D C B A 1 2 4 3 Description Material Finish Body Pin Insulation Gold Teflon Gold Teflon Brass Brass CONNECTOR CITY 575 SE ASHLEY PLACE GRANTS PASS, OR 97526 PH (541)-471-6256 FAX (541)-471-6251 Date: Sheet 1 of 1 Revision: Title Part No. Dimensions: MCX MALE RIGHT ANGLE CABLE END CRIMP FOR RG178 CABLE CONMCX012-R178 1.0 INCHES (mm) 6/8/2006 0.197 (5.00) 0.118 (3.00) RECOMMENDED CABLE STRIPPING DIMENSIONS 0.031 (0.80) RG-178 Cable Crimp Ring Gold Brass Ø0.079 (2.00) 0.197 (5.00) 0.394 (10.00) Ø0.148 (3.75) 0.339 (8.60) 0.165 (4.20) BOYD CHUCK 0.3x3.9x5 GROOVE Snaps Gold BE CU 0.035 (0.90) Ø0.157 (4.00) COVER INSULATOR Ø0.126 (3.20) 0.276 (7.00) CRIMP RING Insulator Teflon Teflon Cover Gold Brass 0.079 (2.00) 0.035 (0.90) 0.173 (4.40) 0.171 (4.35) 0.197 (5.00) SIDE VIEW TOP VIEW |
