BA6208

LINEAR INTEGRATED CIRCUIT

UNISONICTECHNOLOGIESCO.,LTD

3 of 4

www.unisonic.com.tw

QW-R109-004.E



PARAMETER

SYMBOL

RATINGS

UNIT

Power Supply Voltage

18

V

Maximum Output Current

500

mA

DIP-8

500

mW

SIP-9

700

mW

Power Dissipation

SOP-8

450

mW

Operating Temperature

-20 ~ +60

C

Storage Temperature

-55 ~ +125

C

Note Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



INPUT TRUTH TABLE

3pin (Ain)

2pin (Bin)

8pin (Aout)

7pin (Bout)

H

L

H

L

L

H

L

H

H

H

L

L

L

L

OPEN

OPEN

Note: HIGH level input is 2.0V or more.

LOW level input is 0.8V or less.



PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Output Saturation Voltage

1.6

V

High

2.0

V

Input Level Voltage

Low

0.8

V

Output Current

200

mA

Standby Supply Current

Ain=Low, Bin= Low

0.4

mA

Input High Level Current

400

μA

Note: A diode that absorbs at least 500mA is built in to give protection against surge currents with a pulse width of

10 ms and a duty ratio of 10% or less.
