F6908
LINEAR INTEGRATED CIRCUIT
UNISONICTECHNOLOGIESCO.,LTD
2 of 7
www.unisonic.com.tw
QW-R109-016.F
PIN CONFIGURATION
PIN DESCRIPTION
PIN NO
PIN NAME
FUNCTION
1
OUT2
Output 2
2
HO
Hall signal output pin
3
LD
Capacitor terminal for Lock detection, Auto restart
4
VCC
Power supply pin
5
H+
Hall signal input pin +
6
H-
Hall signal input pin -
7
OUT1
Output 1
8
GND
GROUND
