free-air temperature (unless otherwise noted) (see Note 3 and Table 1)]

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

(Note 1)

MAX

UNIT

DRIVER SECTION

Maximum Data Rate

Switching

150

250

Kbit/s

Pulse Skew (Note 4)

300

ns

Slew Rate, Transition Region

SR(tr)

5

35

V/μs

3

35

RECEIVER SECTION

Propagation Delay Time, Low-

to High-Level Output

300

ns

Propagation Delay Time, High-

to Low-Level Output

300

ns

Output Enable Time

200

ns

Output Disable Time

200

ns

Pulse Skew (Note 4)

300

ns

2. Short-circuit durations should be controlled to prevent exceeding the device absolute power-dissipation

ratings, and not more than one output should be shorted at a time.
