UNISONIC TECHNOLOGIES CO., LTD

U74LVC2G17

CMOS IC

www.unisonic.com.tw

1 of 5

QW-R502-356.B

DUAL SCHMITT-TRIGGER

BUFFER



DESCRIPTION

The UTC U74LVC2G17 is a high-performance, low-power,

low-voltage, Si-gate CMOS device which provides two independent

buffers with Schmitt trigger action. It is capable of transforming

slowly changed input signals into sharply defined, jitter-free output

signals.



FEATURES

* Operate From 1.65V to 5.5V

* 5 V tolerant input/output for interfacing with 5 V logic

*±24mA output drive (VCC = 3.3V)

* CMOS low-power consumption and high noise immunity

* IOFF Supports Partial-Power-Down Mode Operation

* Latch-up performance exceeds 100mA

* Specified from -40 °C to +85 °C



ORDERING INFORMATION

Ordering Number

Package

Packing

Lead Free

Halogen Free

U74LVC2G17L-AL6-R

U74LVC2G17G-AL6-R

SOT-363

Tape Reel



MARKING
