UNISONIC TECHNOLOGIES CO., LTD

U74CBT3257

CMOS IC

www.unisonic.com.tw

1 of 5

QW-R502-922.C

4-BIT 1-OF-2 FET

MULTIPLEXER/

DEMULTIPLEXER



DESCRIPTION

The U74CBT3257 is a 4-bit 1-of-2 high-speed TTL-compatible

FET multiplexer/demultiplexer. The low on-state resistance of the

switch allows connections to be made with minimal propagation

delay.

Output-enable ( OE ) and select-control (S) inputs select the

appropriate B1 and B2 outputs for the A-input data.



FEATURES

* VCC Operating Range From 4V to 5.5V

* Bidirectional Data Flow, With minimal Propagation Delay

* Low ON-State Resistance (RON) Characteristics (RON =5Ω Typ.)

* Low Power Consumption ICC =3μA (Max)



ORDERING INFORMATION

Ordering Number

Package

Packing

U74CBT3257G-R16-R

SSOP-16

Tape Reel

U74CBT3257G-P16-R

TSSOP-16

Tape Reel



MARKING

SSOP-16

TSSOP-16
