U74LVC2G86G-S08-R datasheet(4/5 Pages) UTC

4 / 5 page

U74LVC2G86

CMOS IC

UNISONICTECHNOLOGIESCO.,LTD

4 of 5

www.unisonic.com.tw

QW-R502-791.B



ELECTRICAL CHARACTERISTICS(Cont.)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Quiescent Supply Current

ICC

VIN=5.5V or GND, IOUT=0

VCC=1.65 ~ 5.5V

μA

Additional Quiescent Supply

Current Per Input Pin

∆ICC

VCC=3 ~ 5.5V, One input at

VCC-0.6V, Other inputs at VCC or

GND

500

μA

Input Capacitance

VCC=3.3V, VIN=VCC or GND



SWITCHING CHARACTERISTICS (TA =25°C , unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Propagation delay from input

(A or B) to output(Y)

tPLH/tPHL

VCC=1.8V±0.15V, CL=30pF

4.1

9.9

VCC=2.5V±0.2V, CL=30pF

5.7

VCC=3.3V±0.3V, CL=50pF

1.6

4.7

VCC=5V±0.5V, CL=50pF

1.4

3.6



OPERATING CHARACTERISTICS (TA =25°C , unless otherwise specified)

PARAMETER

SYMBOL

TEST CONDITIONS

MIN

TYP

MAX

UNIT

Power Dissipation

Capacitance

CPD

VCC=3.3V, f=10MHZ
