UNISONIC TECHNOLOGIES CO., LTD

UT2302

Power MOSFET

www.unisonic.com.tw

1 of 5

QW-R502-114.H

N-CHANNEL

ENHANCEMENT MODE



DESCRIPTION

The UTC UT2302 is N-channel Power MOSFET, designed with

high density cell, with fast switching speed, ultra low on-resistance,

and excellent thermal and electrical capabilities.

Used in commercial and industrial surface mount applications

and suited for low voltage applications such as DC/DC converters.



SYMBOL

2.Gate

1.Source

3.Drain



ORDERING INFORMATION

Ordering Number

Package

Pin Assignment

Packing

1

2

3

UT2302G-AE2-R

SOT-23-3

S

G

D

Tape Reel

UT2302G-AE3-R

SOT-23

S

G

D

Tape Reel

Note: Pin Assignment: G: Gate

D: Drain

S: Source



MARKING

23BG
