2 / 5 page ![]() UP2003 Power MOSFET UNISONICTECHNOLOGIESCO.,LTD 2 of 5 www.unisonic.com.tw QW-R502-202.C ABSOLUTE MAXIMUM RATINGS (TC = 25°C, unless otherwise specified) PARAMETER SYMBOL RATINGS UNIT Drain Source Voltage VDSS -25 V Gate Source voltage VGSS ±20 V Continuous Drain Current ID -9 A Pulsed Drain Current (Note 1) IDM -36 Power Dissipation PD 2.5 W Junction Temperature TJ +150 °C Storage Temperature TSTG -55 ~ +150 Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged. Absolute maximum ratings are stress ratings only and functional device operation is not implied. THERMAL DATA PARAMETER SYMBOL MIN TYP MAX UNIT Junction-to-Ambient θJA 50 °C/W Junction-to-Case θJC 25 °C/W ELECTRICAL CHARACTERISTICS (TC =25°C, unless otherwise specified) PARAMETER SYMBOL TEST CONDITIONS MIN TYP MAX UNIT OFF CHARACTERISTICS Drain-Source Breakdown Voltage BVDSS VGS =0V, ID=-250µA -25 V Drain Source Leakage Current IDSS VDS =-25V, VGS =0V -1 µA Gate-Body Leakage Current IGSS VDS =0V, VGS =±20V ±100 nA ON CHARACTERISTICS Gate-Threshold Voltage VGS(TH) VDS =VGS, ID =-250µA -1.0 -1.5 -3.0 V On-State Drain Current (Note 2) ID(ON) VDS = -5V, VGS = -10V -50 A Drain-Source On-Resistance (Note 2) RDS(ON) VGS =-4.5V, ID =-7A 25 35 mΩ VGS =-10V, ID =-9A 15 20 DYNAMIC PARAMETERS Input Capacitance CISS VDS =-15V, VGS =0V, f=1MHz 1610 pF Output Capacitance COSS 410 Reverse Transfer Capacitance CRSS 200 SWITCHING PARAMETERS (Note 3) Gate to Source Charge QG VDS =-12.5V(BR)DSS, VGS =-10V, ID =-9 A 17 24 nC Gate Charge at Threshold QGS 5 Gate to Drain Charge QGD 6 Turn-ON Delay Time tD(ON) VDS =-12.5V, ID≈-1A, VGS =-10V, RGS =6Ω ,RL=1Ω 6.2 9.3 ns Turn-ON Rise Time tR 10 Turn-OFF Delay Time tD(OFF) 18 Turn-ON Delay Time tD(ON) 10 Turn-OFF Fall-Time tF 5 SOURCE- DRAIN DIODE RATINGS AND CHARACTERISTICS Diode Continuous Forward Current IS -9 A Diode Pulse Current (Note 1) ISM -36 Forward Voltage (Note 2) VSD IF=IS, VGS=0V -1.2 V Note: 1. Pulse width limited by maximum junction temperature. 2. Pulse test: Pulse Width ≤ 300μsec, Duty Cycle ≤ 2% 3. Independent of operating temperature. |
|
|
