UT40N03T

Power MOSFET

UNISONICTECHNOLOGIESCO.,LTD

2 of 5

www.unisonic.com.tw

QW-R502-172.G



ABSOLUTE MAXIMUM RATINGS

PARAMETER

SYMBOL

RATINGS

UNIT

Drain-Source Voltage

30

V

Gate-Source Voltage

±25

V

Continuous Drain Current

28

A

Pulsed Drain Current

95

A

Total Power Dissipation

TO-220/TO-263

31.25

W

TO-251/ TO-252

DFN-8(3×3)

41

Junction Temperature

+150

°C

Storage Temperature

-55 ~ +150

°C

Note: Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

TO-220/TO-263

62

°C/W

TO-251/ TO-252

60

DFN-8(3×3)

65

Junction to Case

TO-220/TO-263

4

°C/W

TO-251/ TO-252

DFN-8(3×3)

3
