Preliminary

DS40143B-page 3

PIC16C55X(A)

Table of Contents

1.0

General Description......................................................................................................................................................................5

2.0

PIC16C55X(A) Device Varieties...................................................................................................................................................7

3.0

Architectural Overview .................................................................................................................................................................9

4.0

Memory Organization ................................................................................................................................................................ 13

5.0

I/O Ports .................................................................................................................................................................................... 23

6.0

Timer0 Module .......................................................................................................................................................................... 29

7.0

Special Features of the CPU..................................................................................................................................................... 35

8.0

Instruction Set Summary ........................................................................................................................................................... 51

9.0

Development Support................................................................................................................................................................ 63

10.0

Electrical Specifications............................................................................................................................................................. 67

11.0

Packaging Information............................................................................................................................................................... 79

Appendix A:

Enhancements............................................................................................................................................................ 87

Appendix B:

Compatibility ............................................................................................................................................................... 87

INDEX .................................................................................................................................................................................................. 89

PIC16C55X(A) Product Identification System...................................................................................................................................... 95

To Our Valued Customers

We constantly strive to improve the quality of all our products and documentation. To this end, we recently con-

verted to a new publishing software package which we believe will enhance our entire documentation process and

product. As in any conversion process, information may have accidently been altered or deleted. We have spent an

exceptional amount of time to ensure that these documents are correct. However, we realize that we may have

missed a few things. If you ﬁnd any information that is missing or appears in error from the previous version of this

data sheet (PIC16C55X(A) Data Sheet, Literature Number DS40143B), please use the reader response form in the

back of this data sheet to inform us. We appreciate your assistance in making this a better document.
