MB6FU

SCHOTTKY BRIDGE

UNISONICTECHNOLOGIESCO.,LTD

2 of 4

www.unisonic.com.tw

QW-R202-039.A



Single phase, half wave, 60Hz, resistive or inductive load.

For capacitance load,derate current by 20%.

PARAMETER

SYMBOL

RATINGS

UNIT

DC Blocking Voltage

600

V

RMS Voltage

420

V

Repetitive Peak Reverse Voltage

600

V

Average Forward Rectified Current

1.0

A

Peak Forward Surge Current, 8.3ms Single Half Sine-Wave

Superimposed on Rated Load

35

A

Operating Junction Temperature Range

-55~+125

°C

Storage Temperature Range

-55~+150

°C

Notes: 1. Absolute maximum ratings are those values beyond which the device could be permanently damaged.

Absolute maximum ratings are stress ratings only and functional device operation is not implied.

2. Mounted on glass epoxy pc board with 1.3mm



THERMAL DATA

PARAMETER

SYMBOL

RATINGS

UNIT

Junction to Ambient

60

°С/W

Note: Measured at 1.0 MHz and applied reverse voltage of 4.0V D.C.



PARAMETER

SYMBOL

TEST CONDITIONS

MIN TYP MAX UNIT

Instantaneous Forward Voltage

1.1

V

5.0

μA

DC Reverse Current at Rated DC Blocking

Voltage

500

μA
